ultra-portable pro-mixerand audio interface
TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine. mix 6 stereo input channels, use tempo sync, discover the internal synthesizer and sequencer or use the built-in tuner. MFi compatibility even lets you connect to your iOS devices.
visit store
TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine. mix 6 stereo input channels, use tempo sync, discover the internal synthesizer and sequencer or use the built-in tuner. MFi compatibility even lets you connect to your iOS devices.
visit store
watch full video
smallest of its kind.
TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose to have the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer. with more than meets the eye, TX–6 is packed full of features and connectivity options.
visit store
TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose to have the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer. with more than meets the eye, TX–6 is packed full of features and connectivity options.
visit store
size is only half the story.
battery powered
the rechargeable battery holds for about 8 hours. for energy efficiency, the display automatically goes to sleep when not in use, and led strength is completely adjustable.
synthesizer & sequencer
TX–6 also functions as a portable synthesizer and sequencer with 4 oscillator waveforms and 4 synthesized drum sounds. use tempo sync to stay on the beat.
8 built-in effects
explore send effects like reverb, chorus and delay, and creative effects freeze, tape, filter, and distortion. each channel has a three-band eq and adjustable compressor.
quality and engineering
TX–6 is a sturdy little machine. encased in cnc aluminum with 2k molding, custom-made encoders and faders, and custom pcb - engineered for portability.
wireless connectivity
with ble, you can use TX–6 as a wireless controller for other ble midi devices or trigger and sync the internal synth and sequencer from other sources.
super slimline cables
high quality, slimline cables custom-made for TX–6. the narrow profile allows you to use all 6 channels at once and makes for an easy pack down.
customizable interface
when you're ready for the studio, use TX–6 as a 12 channel audio interface and connect to any daw over usb-c. MFi also allows you to connect to iOS devices.
djmode
turn TX–6 on its side and use it as a dj mixer. turn channel 1 into a fader to crossfade between the channel 5 and 6 so you can fade or cut between the two.
6.35 + 3.5 mm output
connect your audio output through 3.5 mm mini jack or use the included and removable 6.35 mm jack to 3.5 mm mini jack adapter.
field bags
designed to fit TX–6 field mixer and constructed in heavy duty fabric and hardware, field bags are designed for durability, ready to be used out in the field. explore field bags.
connect TX–6 to your computer via usb-c to use it as A multi-functional 24-bit 48kHz audio interface. connect to your daw for 12 channel multitrack recording or record direct to usb storage.
USE THE USB-C TO LIGHTNING CABLE FOR DIRECT CONNECTION TO YOUR SMARTPHONE, INSTANTLY MIX TRACKS ON THE GO.
multitrack elegance.
the first portable pro-mixer that can be used as a multi-functional 24-bit 48kHz audio interface that has an instrument tuner, built-in digital fx, synthesizer and drum machine. connect to your daw for 12 channel multitrack recordings. use the internal synth and sequencer, or control them via external midi device. with MFi you can even connect to your iOS device.
visit store
the first portable pro-mixer that can be used as a multi-functional 24-bit 48kHz audio interface that has an instrument tuner, built-in digital fx, synthesizer and drum machine. connect to your daw for 12 channel multitrack recordings. use the internal synth and sequencer, or control them via external midi device. with MFi you can even connect to your iOS device.
visit store
on the TOP side of TX–6 you'll find the usb-c port and 6 stereo channel inputs. field audio cables are custom made for use with TX–6, the narrow profile allows you to use all 6 channels at once.
on the BOTTOM side of TX–6 are the aux and cue buttons, as well as their inputs, and a main out. the main include a jack adapter that takes the input from 3.5 mm to 6.35 mm.
introducing the field system™ black
by extending the anodization time of field system™ we were able to obtain its darkened aluminum. we kept the diffused overmold for accents but altered the pot, encoder and slider knobs in scales of gray to match OP–XY. tldr; anodization thickens the natural oxide layer onthe surface of metal parts and offers greater durability.
explore
by extending the anodization time of field system™ we were able to obtain its darkened aluminum. we kept the diffused overmold for accents but altered the pot, encoder and slider knobs in scales of gray to match OP–XY. tldr; anodization thickens the natural oxide layer onthe surface of metal parts and offers greater durability.
explore
the field system™
TX–6 is part of our ultra-portable sound recording and performance system. all battery-powered, rechargeable via usb-c and with full interconnectivity (midi and high resolution audio). compatible with iOS, macOS, and windows. it's the most powerful, highest quality, portable system in the world 'as we know it'.
explore
TX–6 is part of our ultra-portable sound recording and performance system. all battery-powered, rechargeable via usb-c and with full interconnectivity (midi and high resolution audio). compatible with iOS, macOS, and windows. it's the most powerful, highest quality, portable system in the world 'as we know it'.
explore
EXPLORE ALL FIELD SYSTEM™ COMPONENTS:
visit store
TX–6 specifications
TX–6 highlights
inputs and outputs
24-bit/48kHz usb interface3.5 mm mini jack to 6.3 mm jackheadset mic inputaux outputconnect to iPhone®, lightning cablestereo or mono for each input
dimensions and weight
90 mm (102 mm with adapter) x 62 mm x 23 mm160 g / 5.6 oz
- 6 stereo input connectors
- 2 stereo output connectors
- 1 stereo headphones connector with headset microphone support
- usb audio / midi interface
- bluetooth low energy radio interface
- rechargeable battery
- 8h battery life
- 48x64 pixel monochrome display
inputs and outputs
24-bit/48kHz usb interface3.5 mm mini jack to 6.3 mm jackheadset mic inputaux outputconnect to iPhone®, lightning cablestereo or mono for each input
dimensions and weight
90 mm (102 mm with adapter) x 62 mm x 23 mm160 g / 5.6 oz
electrical characteristics
audio inputs:impedance 10 kOhmanalog gain 0 - 42 dBmax level 13 dBu, 3.5 VrmsTLV320ADC3140 burr-brown™SNR ~ 102 dBA
audio output (main and aux):max level 8 dBu, 2 Vrmscirrus logic masterhifi CS43131SNR > 120 dBA
audio output (cue):max level 2 dBu, 1 Vrmscirrus logic CS47L35SNR > 110 dBA
audio inputs:impedance 10 kOhmanalog gain 0 - 42 dBmax level 13 dBu, 3.5 VrmsTLV320ADC3140 burr-brown™SNR ~ 102 dBA
audio output (main and aux):max level 8 dBu, 2 Vrmscirrus logic masterhifi CS43131SNR > 120 dBA
audio output (cue):max level 2 dBu, 1 Vrmscirrus logic CS47L35SNR > 110 dBA
ultra-portable pro-mixerand audio interface.
TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine.
visit store
TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine.
visit store
watch full video
smallest of its kind.
TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose tohave the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer.
TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose tohave the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer.
size is only half the story.
battery powered
THE RECHARGEABLE BATTERY HOLDS FOR ABOUT 8 HOURS. FOR ENERGY EFFICIENCY, THE DISPLAY AUTOMATICALLY GOES TO SLEEP WHEN NOT IN USE, AND LED STRENGTH IS COMPLETELY ADJUSTABLE.
THE RECHARGEABLE BATTERY HOLDS FOR ABOUT 8 HOURS. FOR ENERGY EFFICIENCY, THE DISPLAY AUTOMATICALLY GOES TO SLEEP WHEN NOT IN USE, AND LED STRENGTH IS COMPLETELY ADJUSTABLE.
instrumentrecording
TX–6 ALSO FUNCTIONS AS A PORTABLE SYNTHESIZER AND SEQUENCER WITH 4 OSCILLATOR WAVEFORMS AND 4 SYNTHESIZED DRUM SOUNDS. USE TEMPO SYNC TO STAY ON THE BEAT.
TX–6 ALSO FUNCTIONS AS A PORTABLE SYNTHESIZER AND SEQUENCER WITH 4 OSCILLATOR WAVEFORMS AND 4 SYNTHESIZED DRUM SOUNDS. USE TEMPO SYNC TO STAY ON THE BEAT.
8 built-in effects
WHEN YOU'RE READY FOR THE STUDIO, USE TX–6 AS A 12 CHANNEL AUDIO INTERFACE AND CONNECT TO ANY DAW OVER USB-C. MFI ALSO ALLOWS YOU TO CONNECT TO IOS DEVICES.
WHEN YOU'RE READY FOR THE STUDIO, USE TX–6 AS A 12 CHANNEL AUDIO INTERFACE AND CONNECT TO ANY DAW OVER USB-C. MFI ALSO ALLOWS YOU TO CONNECT TO IOS DEVICES.
djmode
TURN TX–6 ON ITS SIDE AND USE IT AS A DJ MIXER. TURN CHANNEL 1 INTO A FADER TO CROSSFADE BETWEEN THE CHANNEL 5 AND 6 SO YOU CAN FADE OR CUT BETWEEN THE TWO.
TURN TX–6 ON ITS SIDE AND USE IT AS A DJ MIXER. TURN CHANNEL 1 INTO A FADER TO CROSSFADE BETWEEN THE CHANNEL 5 AND 6 SO YOU CAN FADE OR CUT BETWEEN THE TWO.
wireless connectivity
WITH BLE, YOU CAN USE TX–6 AS A WIRELESS CONTROLLER FOR OTHER BLE MIDI DEVICES OR TRIGGER AND SYNC THE INTERNAL SYNTH AND SEQUENCER FROM OTHER SOURCES.
WITH BLE, YOU CAN USE TX–6 AS A WIRELESS CONTROLLER FOR OTHER BLE MIDI DEVICES OR TRIGGER AND SYNC THE INTERNAL SYNTH AND SEQUENCER FROM OTHER SOURCES.
CONNECT TX–6 TO YOUR COMPUTER VIA USB-C TO USE IT AS A MULTI-FUNCTIONAL 24-BIT 48KHZ AUDIO INTERFACE. CONNECT TO YOUR DAW FOR 12 CHANNEL MULTITRACK RECORDING OR RECORD DIRECT TO USB STORAGE.
USE THE USB-C TO LIGHTNING CABLE FOR DIRECT CONNECTIONTO YOUR SMARTPHONE, INSTANTLY MIX TRACKS ON THE GO.
dynamic soundfor any occasion.
the first portable pro-mixer that can be used as a multi-functional 24-bit 48kHz audio interface that has an instrument tuner, built-in digital fx, synthesizer and drum machine. connect to your daw for 12 channel multitrack recordings. use the internal synth and sequencer, or control them via external midi device. with MFi you can even connect to your iOS device.
visit store
the first portable pro-mixer that can be used as a multi-functional 24-bit 48kHz audio interface that has an instrument tuner, built-in digital fx, synthesizer and drum machine. connect to your daw for 12 channel multitrack recordings. use the internal synth and sequencer, or control them via external midi device. with MFi you can even connect to your iOS device.
visit store
ON THE TOP SIDE OF TX–6 YOU'LL FIND THE USB-C PORT AND 6 STEREO CHANNEL INPUTS. FIELD AUDIO CABLES ARE CUSTOM MADE FOR USE WITH TX–6, THE NARROW PROFILE ALLOWS YOU TO USE ALL 6 CHANNELS AT ONCE.
ON THE BOTTOM SIDE OF TX–6 ARE THE AUX AND CUE BUTTONS, AS WELL AS THEIR INPUTS, AND A MAIN OUT. THE MAIN INCLUDE A JACK ADAPTER THAT TAKES THE INPUT FROM 3.5 MM TO 6.35 MM
introducingfield system™ black.
by extending the anodization time of field system™ we were able to obtain its darkened aluminum. we kept the diffused overmold for accents but altered the pot, encoder and slider knobs in scales of gray to match OP–XY. tldr; anodization thickens the natural oxidelayer on the surface of metal parts andoffers greater durability.
explore
by extending the anodization time of field system™ we were able to obtain its darkened aluminum. we kept the diffused overmold for accents but altered the pot, encoder and slider knobs in scales of gray to match OP–XY. tldr; anodization thickens the natural oxidelayer on the surface of metal parts andoffers greater durability.
explore
the field system™
TX–6 is part of our ultra-portablesound recording and performance system.all battery-powered, rechargeable via usb-cand with full interconnectivity (midi and high resolution audio). compatible with iOS, macOS, and windows. it's the most powerful, highest quality, portable system in the world'as we know it'.
explore
TX–6 is part of our ultra-portablesound recording and performance system.all battery-powered, rechargeable via usb-cand with full interconnectivity (midi and high resolution audio). compatible with iOS, macOS, and windows. it's the most powerful, highest quality, portable system in the world'as we know it'.
explore
EXPLORE ALL FIELD SYSTEM™ COMPONENTS:
OP–XY
visit store
CM–15 field microphone
visit store
CM–15 field microphone
visit store
TP–7 field recorder
visit store
TP–7 field recorder
visit store
TX–6 field mixer
visit store
TX–6 field mixer
visit store
OP–1 field
visit store
small field bag
visit store
field accordion bag
visit store
field delivery bag
visit store
TX–6specifications
TX–6 highlights
electrical characteristics
audio inputs:impedance 10 kOhmanalog gain 0 - 42 dBmax level 13 dBu, 3.5 VrmsTLV320ADC3140burr-brown™SNR ~ 102 dBA
audio output (main & aux):max level 8 dBu, 2 Vrmscirrus logic masterhifi CS43131SNR > 120 dBA
audio output (cue):max level 2 dBu, 1 Vrmscirrus logic CS47L35SNR > 110 dBA
- 6 stereo input
- 2 stereo output
- 1 stereo headphones connector with headset microphone support
- usb audio / midi
- rechargeable battery
- bluetooth low energy radio interface
- 8h battery life
- 48x64 pixel display
electrical characteristics
audio inputs:impedance 10 kOhmanalog gain 0 - 42 dBmax level 13 dBu, 3.5 VrmsTLV320ADC3140burr-brown™SNR ~ 102 dBA
audio output (main & aux):max level 8 dBu, 2 Vrmscirrus logic masterhifi CS43131SNR > 120 dBA
audio output (cue):max level 2 dBu, 1 Vrmscirrus logic CS47L35SNR > 110 dBA
inputs and outputs
handling
ambient working temperature:0-50°c (32-122°f)
ambient storage temperature:0-30°c (32-86°f)
clean the shell of the unit with a microfibre cloth. use pressurized air to remove dust from the faders.
to keep the battery healthy, the unit should be charged at least every 6 months. if not used for a long time, it may not charge again.
- 24-bit / 48kHz usb interface
- 3.5 mm mini jack to 6.3 mm jack
- headset mic input
- aux output
- connect to iPhone®
with lightning cable - stereo or mono for
each input
handling
ambient working temperature:0-50°c (32-122°f)
ambient storage temperature:0-30°c (32-86°f)
clean the shell of the unit with a microfibre cloth. use pressurized air to remove dust from the faders.
to keep the battery healthy, the unit should be charged at least every 6 months. if not used for a long time, it may not charge again.
for more tech specsvisit the guide
